ACO便携式测振仪数显TYPE3116青岛平山郭15854210565
产品详情
ACO便携式测振仪数显TYPE3116青岛平山郭15854210565
ACO便携式测振仪数显TYPE3116青岛平山郭15854210565
ACO便携式测振仪数显TYPE3116青岛平山郭15854210565
ITEM
| Measurement range | Acceleration(ACC) | 0.02～200m/s² RMS |
| Velocity(VEL) | 0.02～200mm/s RMS | |
| Displacement(DISP) | 2～2000μm EQp-p | |
| Frequency range | Acceleration(ACC) | 3Hz～10kHz |
| Velocity(VEL) | 10Hz～1kHz(Compliant with JIS B0907-1989) | |
| Displacement(DISP) | 10Hz～300Hz | |
| Measurement range | Acceleration(ACC) | 20, 200m/s² RMS |
| Velocity(VEL) | 20, 200mm/s RMS | |
| Displacement(DISP) | 200, 2000μm EQp-p | |
| Display characteristics | Acceleration(ACC) | RMS, EQ Peak, Peak |
| Velocity(VEL) | RMS, EQ Peak, Peak | |
| Displacement(DISP) | RMS, EQ Peak, EQp-p, Peak | |
| EQ Peak＝RMS×√2，EQp-p＝EQ Peak×2 | ||
| Dynamic characteristic (Time constant) | RMS, EQ Peak, EQp-p；1s | |
| Peak；50msec(rise)/3s(decay) |
¥3540.00
