ONOSOKKI小野测器信号线MX-7115青岛平山郭-158-54210565

货号: #MX-7115

库存: 37

品牌:

¥2140.00 ¥1120.00

简介

ONOSOKKI小野测器信号线MX-7115青岛平山郭-158-54210565

分类: 工控传动,

产品详情

ONOSOKKI小野测器信号线MX-7115青岛平山郭-158-54210565

Model name	Length	Detector side	Outer view	Counter side
Signal cable (Detector Counter)
MX-005	5 m	MP-610/610B/750/910/9100/ 912/9120/920/9200/940**/940A/963 MP-810/820/830/837 (MP-081+MX-005 series)	It enables to connect by using MX-000 series+MX-603 or MX-6031 cables when the input plug can be connected to the counter with terminal strip.	TM-225 CT-6520B FV-1100/1400/1500/ 5300 SR-506/512A
MX-010	10 m
MX-015*	15 m
MX-020	20 m
MX-101	1.5 m	MP-162/930/931/935/936/950/954/962 FG-1200/1300	It enables to connect by using MX-000 series+MX-603 or MX-6031 cables when the input plug can be connected to the counter with terminal strip. * The followings are directly-attached cables.MP-930:0.5 mMP-935:1 mMP-936:1 mMP-950:0.5 mMP-954:0.5 mMP-962:0.5 m	TM-225 CT-6520B(Discon) FV-1100/1400/ 1500/5300 SR-506/512A**
MX-105	5 m
MX-110	10 m
MX-115	15 m
MX-120	20 m
MX-505	5m	MP-610/610B/750/ 910/9100/912/9120/ 920/9200/940**/940A/963 MP-810/820/830/837 (MP-081+MX-500 series)	* The TM-5100 has the terminal strip socket for signal input/output. To connect to the TM-5100, it is required to process the cable end from a crimp terminal to be open status.	TM-5100 TM-225(Discon) TM-2100 series TM-3100 series TM-4100 series FV-1400**/1500 PA-150
MX-510	10 m
MX-520	20 m
MX-5205	5 m	MP-610/610B/750/ 910/9100/912/9120/ 920/9200/940**/940A/963 MP-810/820/830/837 (MP-081+MX-5205)		TM-4200 series TM-4300 series TM-4400 series
MX-7105	5 m	MP-981 LG-916** LG-9200 MP-9820	* The TM-5100 has the terminal strip socket for signal input/output. To connect to the TM-5100, it is required to process the cable end from a crimp terminal to be open status.	TM-5100 TM-3100 series TM-4100 series FV-1400/1500 PA-150
MX-7110	10 m
MX-7115	15 m*
MX-7120	20 m
MX-7305	5 m	MP-981 MP-9820 LG-9200 LG-916**		TM-4200 series TM-4300 series TM-4400 series
MX-7310	10 m
MX-7320	20 m
MX-8105	5 m	MP-981 MP-9820 LG-9200 LG-916**		CT-6520B CT-6710/CT-6700 FV-5300 TS-2700(cannot be used with the LG-916,LG-9200.) TS-2800(cannot be used with the LG-916,LG-9200.) TS-3200A(cannot be used with the LG-916**,LG-9200.)
MX-8110	10 m*
MX-8115	15 m*
MX-8120	20 m*
RP-0169	5 m	RP-432Z		TM-2100 series TM-3100 series TM-4200 series TM-4300 series PA-150
