TD-700T

 TEDS

TD-700T is digital indicator to measure and display physical quantity such as load, pressure, and torque working with strain gauge transducer.

Color graphic LCD display, high-speed sampling, TEDS function (IEEE1451.4 class 2 mix mode interface compliance) and various hold function, the various functions are condensed in DIN half-size body.

Various in the scene, we will provide the best performance.

Input Signal RangeStrain gauge type transducer ±3.2mV/V BridgeBridge Excitation VoltageDC 10V or 2.5V ±10% selectable   Max. Current: 30mACalibrationRange0.3 to 3.2mV/VAccuracy0.1%F.S. (Sensitivity 0.5mV/V or more)MethodActual Load, Equivalent Load, TEDSAccuracyNon-linearity< 0.01%F.S. + 1Digit (@ 1mV/V Input)Zero Drift< 0.5μV / deg C (Input Equivalent Value)Gain Drift< ±0.005% F.S./ deg CAnalog to Digital Converting Rate4,000 times / second
20,000 times / second (when HOLD mode selected)D/A Output4000 times per second, isolated output,
±1 - ±10V voltage output (set in 1V steps) and about 1/59000
resolution (when set to ±10V), or 4–20mA current output and about 1/43000 resolutionTEDSIEEE1451.4 Mix Mode Interface Class2DisplayDisplay Unit2.4 inch TFT color LCDRange5 digits, ±99999Times4, 6, 10, 20 times /secondModeSelect Normal, Compare, HoldResolutions1 / 99999Data Hold Functions
（Sampling 20,000 times / second）Sample, Peak, Bottom,
Peak to Peak, Peak and Bottom, Average,
Time Blocking Available except Sample HoldComparator FunctionsContact Signal
(4 point)High-High Limit(HH), High Limit(HI), Low Limit(LO), Low-Low Limit(LL)Range-99999 to 99999ModeSelect Always, Stable, Hold, No CompareCompare Speed4,000 times / secFilterDigital Filter
Low-pass Filter 3/10/30/100/300/1000 Hz/None -12dB/oct
Moving Average (16/32/64/128/256/512/1024/2048)Digital ZeroDigital ZeroSet to Zero on specified pointZero TrackingSuppressing to Zero by specifying time duration and level rangeOther FunctionsHH, LL enable/disable, Set near Zero, Digital Zero Limit
Digital Zero Clear, Motion Detect, Digital Offset
Minimum Scale, TEDS, Calibration Value Lock, Setting Lock,
Static Strain Mode, Compare Output Control,
Contact IN/OUT check Key LockControl I/OInput SignalHold, Digital Zero, Judge, Clear,
Change Settings (Setting1, Setting2)Input Signal TypeContact or Open CollectorOutput SignalS1(HH), S2(HI), S3(LO), S4(LL), OK(OK)Output Signal TypeOpen Collector OutputPower supply
（ DC power supply specifications）DC12V to 24V 9WEnvironmentOperating Temperature Range0 to 40 deg CStorage Temperature Range-20 to 60 deg COperating Humidity Range< 85%RH (No condensation)DimensionApprox. 96W x 53H x 132D [mm] (Excluding Protruding Parts)WeightApprox. 300 gRegulationsSafetyInstallation Category I, EN61010-1 Pollution degree: 2/Measurement Category II
CE, UL61010EMCVCCI(Class A), EN61326 For use in industrial locations, EN61000-3-2, EN61000-3-3
