Kowa高像素工业定焦镜头LM5JC10M青岛平山郭-158-54210565

货号: #LM5JC10M

库存: 29

品牌:

¥16520.00 ¥6090.00

分类: 环境设备类,

产品详情

Kowa高像素工业定焦镜头LM5JC10M青岛平山郭-158-54210565

Description

Aperture (F-stop):	1,8 - 16
Aperture (control):	Manual
Application field:	Broadcast, Machine Vision
Back focus in air (mm):	10,3
Control (focus):	Manual
Field of view at minimum working distance, horizontal (mm):	197
Field of view at minimum working distance, vertical (mm):	147
Filter size (mm):	M46 x P0,75
Focal length (mm):	5
Focus range (m):	0,1 - ∞
Megapixel:	10
Mount:	C-mount
Pixel size (µm):	2,5
Resolution, centre (lp/mm):	200
Resolution, margin (lp/mm):	160
Sensor size:	2/3"
Series:	JC10M
Size (mm):	Ø48 X 59,4
TV distortion (%):	-0,33
Temperature range (℃):	-10°C - +50°C
Type of lens:	Fixed Focal Lens
Wavelength range:	Broad Band Coating (400nm – 1000nm)
Weight (g):	120
