orientalmotor东方马达电机CBI560-803T青岛平山技研刘15621198049
Specifications
| Frame Size | 90 mm |
|---|---|
| Output Power | 60 W |
| Type | With Small Terminal Box |
| Shaft/Gear Type | Pinion Shaft Type |
| Gear Ratio | - |
| Time Rating | Continuous |
| Rotation Direction | Depends on the combination gear head. |
| Voltage/ Frequency/ Current | Three-Phase 200 VAC / 50 Hz / 0.6 A Three-Phase 200 VAC / 60 Hz / 0.6 A Three-Phase 220 VAC / 60 Hz / 0.6 A |
| Rated Speed | Three-Phase 200 VAC / 50 Hz: 1300 r/min Three-Phase 200 VAC / 60 Hz: 1550 r/min Three-Phase 220 VAC / 60 Hz: 1600 r/min |
| The Speed When Installing Gearhead | Depends on the combination gear head. |
| Clutch and Brake Static Friction Torque | Crutch: 1.5 N·m、Brake: 1.5 N·m |
| Clutch and Brake Voltage | 24 VDC |
| Clutch and Brake Capacitance | Clutch: 7 W、Brake: 5 W |
| Clutch and Brake Operating Frequency | 100 times/min |
| Mass | 4.1 kg |
¥12400.00
